4023/2x5
4023 - Double access scissor ladder EN131.1-2
| Model | Rungs | Weight | Width D |
Overture N |
Working height B |
Total height M |
Folded length |
|
4023/2x5 |
2x5 | 5,1 | 0,51 | 0,95 | 2,27 | 1,45 | 1,47 |
|
4023/2x6 |
2x6 | 6,1 | 0,54 | 1,15 | 2,50 | 1,70 | 1,75 |
|
4023/2x7 |
2x7 | 7,3 | 0,57 | 1,25 | 2,80 | 1,95 | 2,05 |
|
4023/2x8 |
2x8 | 8,4 |
0,60 | 1,45 | 3,05 | 2,25 | 2,33 |
|
4023/2x10 |
2x10 | 10,9 | 0,66 | 1,85 | 3,57 | 2,75 | 2,88 |
|
4023/2x12 |
2x12 | 13,6 | 0,72 | 2,05 | 4,10 | 3,25 | 3,44 |
Highlights
Approximate maximum working height (m): 4.5
Tilt °: 75
Step (mm): 30
Rung difference (mm): 270
Other details
Ergonomic extruded side uprights.
20mm opening strip.
