8024/2x2

8024 - Scissor ladder with double access and wide step EN131.1-2

Model Rungs Weight Width
D 		Overture
N 		Working
height
B
 Total
height M
 Folded
length

8024/2x2

 2x2 3,2 0,41 0,60 1,49 0,45 0,58

8024/2x3

 2x3 4,6 0,43 0,80 1,72 0,70 0,77

8024/2x4

 2x4 5,6 0,45 0,98 1,95 0,95 1,04

8024/2x5

 2x5 6,8 0,47 1,15 2,19 1,15 1,30

8024/2x6

 2x6 8,2 0,50 1,30 2,42 1,40 1,53

8024/2x7

 2x7 9,4 0,52 1,50 2,65 1,65 1,80

8024/2x8

 2x8 10,5 0,55 1,70 2,88 1,85 2,05

8024/2x9

 2x9 12,2 0,57 1,95 3,11 2,10 2,28

8024/2x10

 2x10 13,8 0,60 2,15 3,35 2,30 2,54

8024/2x12

 2x12 16,5 0,65 2,50 3,81 2,80 3,04

Highlights

Approximate maximum working height (m): 4.5

Tilt °: 68

Step (mm): 80

Rung difference (mm): 230

Other details

High resistance opening tapes.

First step reinforcement straps.

Angled feet that provide more support surface.

High resistance cast iron opening hinge.

Catálogo - 8024 - Español [Download]

Catalogue - 8024 - Français [Download]

Catalog - 8024 - English [Download]
