8042/4x3
8042 - Telescopic transformable ladder 4 sections EN131.1-2
| Model | Rungs | Weight | Width D |
Overture N |
Overture K |
Working height B |
Working height A |
Total height M |
Total height J |
Folded length |
|
8042/4x3 |
4x3 | 11,2 | 0,55 | 0,73/1,08 | 0,48/0,76 | 2,22 | 3,60 | 0,90/1,40 | 1,78/2,82 | 1,00 |
|
8042/4x4 |
4x4 | 13,2 | 0,55 | 0,90/1,44 | 0,61/1,05 | 2,76 | 4,50 | 1,15/1,95 | 2,27/3,88 | 1,20 |
|
8042/4x5 |
4x5 | 16,0 | 0,65 | 1,07/1,80 | 0,75/1,34 | 3,30 | 5,60 | 1,40/2,49 | 2,80/4,93 | 1,50 |
|
8042/4x6 |
4x6 | 20,0 | 0,70 | 1,26/2,15 | 0,90/1,63 | 3,85 | 6,70 | 1,70/3,03 | 3,34/6,05 | 1,80 |
Highlights
Approximate maximum working height (m): 7
supported / 4 without support
Tilt °: 75
Step (mm): 30
Rung difference (mm): 280
Other details
Ergonomic extruded side uprights.
It takes up little space, easily
transportable.
Cast aluminium locking handles.
In the scissor position, the ladder can be
folded without removing the seal.
