1060008
10600 - Working ladder and 68 ° access with handrail EN 131.1-2
| Model / Plan download |
3D download | Rungs | Weight | Width D |
Overture K |
Working height A | Vertical height J |
| 1060004_3D | 4 | 5 | 0,50 | 0,47 | 1,45 | 0,92 | |
| 1060005_3D | 5 | 6 | 0,50 |
0,56 | 1,68 |
1,15 |
|
| 1060006_3D | 6 | 7 | 0,50 |
0,66 |
1,91 |
1,38 |
|
| 1060007_3D | 7 | 8 | 0,50 |
0,75 |
2,14 |
1,61 |
|
| 1060008_3D | 8 | 10 |
0,50 |
0,84 |
2,37 |
1,84 |
|
| 1060010_3D | 10 | 13 |
0,50 |
1,03 |
2,83 |
2,30 |
|
| 1060012_3D | 12 | 15 |
0,50 |
1,21 |
3,29 |
2,76 |
Highlights
Maximum aprox. working height (mts): 4.8
Tilt °: 68
Rung (mm): 80
Distance between rungs (mm): 230
More details
Extruded profile.
Work ladder with railings.
Optional second handrail.
