Model / Plan download |
3D download | Rungs | Weight | Width D1/D2 |
Overture folded N |
Overture unfolded N | Platform height | Working height B |
Total height M | Total height folded | Platform O1/O2 |
1010204_3D | 4 | 32 | 0,60/0,88 | 0,62 | 1,28 | 1,00 | 2,50 | 2,02 | 2,48 | 0,60x0,60 |
|
1010205_3D | 5 | 35 | 0,60/1,10 | 0,64 | 1,42 | 1,25 | 2,75 | 2,27 | 2,76 |
0,60x0,60 |
|
1010206_3D |
6 | 41 | 0,60/1,26 | 0,62 | 1,57 | 1,50 | 3,00 | 2,52 | 3,05 |
0,60x0,60 |
|
1010207_3D |
7 | 44 | 0,60/1,41 | 0,66 | 1,72 | 1,75 | 3,25 | 2,77 | 3,33 |
0,60x0,60 |
|
1010208_3D |
8 | 47 | 0,60/1,51 | 0,66 | 1,86 | 2,00 | 3,50 | 3,02 | 3,61 |
0,60x0,60 |
|
1010210_3D |
10 | 56 | 0,60/1,81 | 0,67 | 2,15 | 2,50 | 4,00 | 3,52 | 4,19 |
0,60x0,60 |
|
1010212_3D | 12 | 63 | 0,60/1,91 | 0,69 | 2,42 | 3,00 | 4,50 | 4,02 | 4,76 |
0,60x0,60 |
Highlights
THE PLATFORMS ARE DESIGNED FOR INTERIOR USE, IN CASE OF EXTERIOR USE, CONSULT
Maximum aprox. working height (mts): 5
Tilt °: 60
Rung (mm): 200
Distance between rungs (mm): 250
More details
Extruded profile.
It is fixed and has wheels.
Platform: 600 x 600.
Horizontal resistance to buckling 30 kg.
150mm rear wheel with lever operated brake.
Front carrying straps.
